NIXKZN_EN
| EAN code | 8595057669482 |
| Customs code | 73089059 |
| Weight | 2,3300 kg/m |
| Surface finish | Stainless steel AISI 304 |
| Temperature resistance | -50 - 150 °C |
| Width | 250 mm |
| Height | 50 mm |
| Length | 2000 mm |
| Standards | ČSN EN 61537 |
| Thickness of metal sheet | 0,8 mm |
| Quantity of screws for connecting | 4 |
The joining of the trays is performed by using of the couplings NIXS 100 and by the bolts NIXSM 6X10. Tray is connected directly to accessories (with no connectors – the tray is inserted into the accessory), using NIXSM 6X10 screws.
