EAN code | 8595057673694 |
Customs code | 72224050 |
Weight | 0,7300 kg/m |
Surface finish | Stainless steel AISI 304 |
Temperature resistance | -50 - 150 °C |
Length | 2000 mm |
Standards | ČSN EN 61537 |
Thickness of metal sheet | 0,6 mm |
Dimension A | 127 mm |
Dimension H | 14 mm |
For width of cable tray | 125 mm |
For height of cable tray | 50 - 100 mm |
The fixing of the cover to the tray is done by using of the cover fixture NIXUV.
